anura-select

<anura-select adapter="some-adapter" source="123"></anura-select>

A multi-select component with filtering capabilities

Attributes

adapter

required: yes, live: no, default: -

With which adapter to talk to (to load the values from)

<anura-select adapter="#my-adapter"></anura-select>

source

required: yes, live: on-load, default: -

What metadata field to query in order to get the possible values from. The value type will depend on the adapter that you're using (usually an ID or a UUID)

<anura-select source="123"></anura-select>

filter

required: no, live: yes, default: true or visible for lists with 20+ items

How to handle the search field, possible values:

• true - search field is available, but must be toggled through the search-icon (default)
• false - the search field is not available
• visible - the search field is visible without having to toggle it
• async - implies visible, but fetches the matching values from the DAM (if the DAM supports it). This is useful for large lists.

<anura-select filter="visible"></anura-select>

radio

required: no, live: on-load, default: false

Whether to use radio buttons (i.e. only allow a single selection) instead of checkboxes

<anura-select radio="true"></anura-select>

value

required: no, live: set by component, default: -

The value deriving from the inputs (comma-separated). Can be used to set an initial value, but will only be written to by the component afterwards.

<anura-select value="103"></anura-select>

type

required: no, live: set by component, default: -

The type of field that should be affected. This will be set by your adapter and is specific to the implementation. Don't touch this.

hide-title

required: no, live: on-change, default: false

Whether the title that is displayed inside the select box should still be visible when values are selected. Given the screenshot above:

• false: "Approval: Released, Pending, New"
• true: "Released, Pending, New"

<anura-select hide-title="true"></anura-select>

sort

required: no, live: on-load, default: name-asc

How the options should be sorted, e.g. name-desc or id-asc (-asc is optional/default). Available keys are name, id, value and order, but it depends on your DAM if they are present or make sense.

<anura-select sort="name-desc"></anura-select>

root-node

required: no, live: on-change, default: -

CELUM only, use a different root node for node-referencing fields (needs to reside beneath the actual root node).

<anura-select root-node="123"></anura-select>

depth

required: no, live: on-change, default: 3

CELUM only, when loading a tree, how many child-levels should be fetched

<anura-select depth="3"></anura-select>

skip-levels

required: no, live: on-change, default: -

CELUM only, when loading a tree, how many parent-levels should be skipped (child-nodes will be merged into one big list)

<anura-select skip-levels="1"></anura-select>

value-type

required: no, live: on-change, default: -

Sharedien only, when setting the type to relation, you need to set the entity type of the relation (in addition to the relation identifier as source)

<anura-select type="relation" value-type="my-entity-type" source="my-relation-type""></anura-select>

facets

required: no, live: on-load, default: true

Set this to false to disable faceted search for this component.

<anura-select facets="false"></anura-select>

state

required: no, live: on-load, default: true

Whether the select should maintain its state. This will use the components id to differentiate itself from other components. If you don't provide an ID, a hash of the component will be used. Set it to false to not keep any state at all.

Events

change

standard change event

Fired when the user selects values in the dropdown

Parts

<header part="header">
    <span part="header-title"></span>
    <span part="header-value"></span>
    <button part="select-button header-clear">
        <anura-icon part="header-icon header-icon-clear"></anura-icon>
    </button>
    <button part="select-button header-toggle">
        <anura-icon part="header-icon header-icon-toggle"></anura-icon>
    </button>
</header>
<fieldset part="fieldset">
    <div part="fieldset-title">
        <label part="fieldset-label"></label>
        <span part="fieldset-counter"></span>
        <button part="fieldset-reset"></button>
        <button part="select-button fieldset-filter">
            <anura-icon part="select-icon select-icon-search"></anura-icon>
          </button>
        <button part="select-button fieldset-close" id="fieldset-close" tabindex="1">
            <anura-icon part="select-icon select-icon-close" icon="x"></anura-icon>
        </button>
    </div>
    <input part="fieldset-search">
    <div part="fieldset-body">
        <label part="select-label">
            <input part="select-input">
            <span part="select-name"></span>
            <span part="select-count"></span>
        </label>
        <!-- labels repeat here -->
    </div>
</fieldset>
